BOR-4

Enumeration of all the flights

Designation Launch date Detail
1 - 05.12.1980 First try of "BOR-4" for the orbital flight
2 Cosmos-1374 03.06.1982 Sea landing in the Indian Ocean at 560 km in the south of Cocoa's islands. The Australian reconnaissance planes took detailed photos of the lifting body and its recovery.
3 Cosmos-1145 15-16.03.1983 Sea landing in the Indian Ocean at 560 km in the South of Cocoa's islands, once again watched out by the Australian reconnaissance plane.
4 Cosmos-1517 27.12.1983 To avoid the espionage from the Westerners the lading zone is moved in Black Sea. The braking impulse is given above the North Atlantic Ocean.
5 - 04.07.1984 According to foreign sources the flight took place at 130 km of height with a suborbitale trajectory. The USSR did not confirm this flight.
6 Cosmos-1614 19.12.1984 Sea landing in the Black Sea after accomplishing a turn. The lifting body is lost in sea by the recovery services.
7 - 20.10.1987 According to foreign sources the flight took place at 130 km of height with a suborbitale trajectory. The USSR did not confirm this flight.

Official Flights

Designation
of the USSR
Designation
of the USA
Flight
stage
Launch
date
Hour Orbit's parameters
1 Cosmos-1374 13257/1982-054А Start
Arrival
03.06.1982
03.06.1982
21:36 UTC
23:04 UTC
Perigee, km 167
Apogee, km 222
Inclination, degree 50.6°
Rotation period, min 88.1
2 Cosmos-1445 13883/1983-017А Start
Arrival
15.03.1983
16.03.1983
22:33 UTC
00:25 UTC
Perigee, km 176
Apogee, km 217
Inclination, degree 50.7°
Rotation period, min 88.3
3 Cosmos-1517 14585/1983-125А Start
Arrival
27.12.1983
27.12.1983
10:04 UTC
11:46 UTC
Perigee, km 180
Apogee, km 221
Inclination, degree 50.6°
Rotation period, min 88.8
4 Cosmos-1614 15442/1984-126А Start
Arrival
19.12.1984
19.12.1984
04:04 UTC
05:26 UTC
Perigee, km 173
Apogee, km 223
Inclination, degree 50.7°
Rotation period, min 88.5

BOR 5

Designation Launch date Detail
1 - 04.07.1983 Aborted
2 Model 501 06.06.1984 Successful
3 Model 502 17.04.1985 Improvements
4 Model 503 27.12.1986 Improvements
5 model 504 27.08.1987 Improvements
6 Model 505 22.06.1988 Improvements

BOR's sensors

Measures Number of sensors
on BOR-4
Number of sensors
on BOR-5
aerodynamics studies
Pressure sensors 4 41
Accelerometers 9 10
Angular speed sensors 4 8
Wing position sensors 2 -
Angular accelerometers sensors - 3
Gyro - 3
Elevon's and girder's
sensors
- 6
Moment sensors - 10
Temperatures
Temperature sensors 151 30
Calorimeters 20 83
Fuselage's temperature sensors 1 3
Crystalline sensors of
maximal temperature
83 141
Thermometers with electrical resistors 47 42
Orientation and control of the flight
Control system 10 10
Magnetometer - 18

BOR's flight trajectories

BOR-4, BOR-5, BOR-1, BOR-2, BOR-3, mock-up, orbital plane without pilot, russian soviet, USSR

Caption:
1-Launch; 2-Separation; 3-Descent; 4-Sea landing / Landing
